c. Remove the O-ring from the housing front.
26. REMOVE VANE PUMP HOUSING OIL SEAL
a. Using a screwdriver and shop rag, remove the housing oil seal.
NOTICE: Be careful not to damage the housing front.
27. INSPECT VANE PUMP SHAFT AND BUSH IN HOUSING FRONT
a. Using a micrometer and a caliper gauge, measure the oil clearance.
Maximum clearance: 0.07 mm (0.0028 inch) or less
If the clearance exceeds the maximum, replace the vane pump assy.
28. INSPECT VANE PUMP ROTOR AND VANE PUMP PLATES
a. Using a micrometer, measure the thickness of the vane pump plates.
Minimum thickness: 1.405 to 1.411 mm (0.05531 to 0.05555 inch)
