Shift Cable: Service and Repair
TRANSMISSION CONTROL CABLE ASSY (ATM)
REPLACEMENT
HINT:
^
INSTRUMENT PANEL METER
^
FLOOR SHIFT ASSY
1. REMOVE CONSOLE BOX REAR COVER
2. REMOVE CONSOLE BOX CARPET
3. REMOVE CONSOLE BOX SUB-ASSY REAR
4. REMOVE EXHAUST PIPE ASSY FRONT
5. REMOVE FRONT FLOOR HEAT INSULATOR NO.1
6. REMOVE AIR CLEANER ASSY
7. DISCONNECT TRANSMISSION CONTROL CABLE ASSY
a. Remove the nut, disconnect the transmission control cable assy from the floor shift assy.
b. Using a screwdriver, disconnect the transmission control cable assy from the shift lever plate.
c. Remove the 3 bolts.
d. Pull out the transmission control cable assy from the body.
e. Remove the nut and disconnect the transmission control cable assy from the control shaft lever.
f.
Remove the clip and disconnect the transmission control cable assy from the control cable bracket.
