Customer Interest for Power Distribution Relay: > < Electrical - Multiple Warning Lamps ON/Can't Shift A/T

xD L4-1.8L (2ZR-FE) (2008)

Page 2
background image

1. Locate the instrument panel junction block No. 1 located in the Instrument Panel (as shown in Figure 1).

2. Remove the relay and verify the part number located on the side of the relay.

A.If the part number is 90987-02025 or 90987-02030 replace the relay with the countermeasure relay P/N 90987-02031.

B.If the part number is 90987-02031 then diagnose the specific conditions reported by the customer following the Repair Manual.

3. Connect TIS Techstream and clear any stored DTCs.
