xD L4-1.8L (2ZR-FE) (2008)
/Page-79001.png)
Ignition Relay: Service and Repair
Installation
2ZR-FE ENGINE CONTROL SYSTEM: IGNITION RELAY NO. 1: INSTALLATION
INSTALLATION
1. INSTALL NO. 1 IGNITION RELAY
(a) Install the No. 1 ignition relay.
2. INSTALL INSTRUMENT PANEL BOX
