xD L4-1.8L (2ZR-FE) (2008)
Tire Pressure Monitor Receiver / Transponder: Service and Repair
Installation
TIRE AND WHEEL: TIRE PRESSURE WARNING RECEIVER (w/ Antenna): INSTALLATION
INSTALLATION
1. INSTALL TIRE PRESSURE WARNING RECEIVER ASSEMBLY (w/ Antenna)
(a) Install the tire pressure warning receiver with the bolt.
Torque: 7.5 Nm (76 kgf-cm, 66 in-lbf)
(b) Connect the pressure warning receiver connector.
2. INSTALL ROOF SIDE GARNISH INNER LH See: Body and Frame/Interior Moulding / Trim/Headliner/Service and Repair/Installation
3. INSTALL DECK TRIM SIDE BOARD LH See: Body and Frame/Interior Moulding / Trim/Headliner/Service and Repair/Installation
4. INSTALL LUGGAGE HOLD BELT STRIKER ASSEMBLY See: Body and Frame/Interior Moulding / Trim/Headliner/Service and
Repair/Installation
5. INSTALL REAR DOOR WEATHERSTRIP LH See: Body and Frame/Interior Moulding / Trim/Headliner/Service and Repair/Installation
6. INSTALL REAR DOOR SCUFF PLATE LH See: Body and Frame/Interior Moulding / Trim/Headliner/Service and Repair/Installation
7. INSTALL REAR DECK TRIM COVER See: Body and Frame/Interior Moulding / Trim/Headliner/Service and Repair/Installation
8. INSTALL DECK BOARD ASSEMBLY See: Body and Frame/Interior Moulding / Trim/Headliner/Service and Repair/Installation
9. INSTALL REAR SEAT ASSEMBLY LH See: Body and Frame/Seats/Service and Repair/Rear Seat Assembly (for LH Side)/Installation
10. INSTALL NO. 1 REAR SEAT LEG COVER See: Body and Frame/Seats/Service and Repair/Rear Seat Assembly (for LH Side)/Installation
11. INSTALL NO. 2 REAR SEAT LEG COVER See: Body and Frame/Seats/Service and Repair/Rear Seat Assembly (for LH Side)/Installation
12. INSPECT TIRE PRESSURE WARNING SYSTEM
See: Instrument Panel, Gauges and Warning Indicators/Tire Monitoring System/Testing and Inspection/Initial Inspection and Diagnostic Overview/Test
Mode Procedure
