xD L4-1.8L (2ZR-FE) (2008)
Remote Switch: Service and Repair
Installation
AUDIO / VISUAL: STEERING PAD SWITCH: INSTALLATION
INSTALLATION
CAUTION: Some of these service operations affect the SRS airbag system. Read the precautionary notices concerning the SRS airbag
system before servicing See: Restraint Systems/Air Bag Systems/Service Precautions.
1. INSTALL STEERING PAD SWITCH LH
(a) Engage the 2 claws and the pin.
(b) Install the steering pad switch LH with the screw.
(c) Connect the connector.
2. INSTALL STEERING PAD ASSEMBLY See: Restraint Systems/Air Bag Systems/Air Bag/Service and Repair/Steering Pad/Installation
3. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
Torque: 5.4 Nm (55 kgf-cm, 48 in-lbf)
4. INSPECT SRS WARNING LIGHT See: Restraint Systems/Air Bag Systems/Testing and Inspection/Initial Inspection and Diagnostic
Overview/Diagnosis System
