xD L4-1.8L (2ZR-FE) (2008)
/Page-399002.png)
WINDSHIELD / WINDOWGLASS: POWER WINDOW MASTER SWITCH: REMOVAL
REMOVAL
1. REMOVE FRONT ARMREST BASE UPPER PANEL LH
HINT: Use the same procedure as for the RH side See: Body and Frame/Doors, Hood and Trunk/Doors/Front Door/Service and
Repair/Disassembly.
2. REMOVE POWER WINDOW MASTER SWITCH
(a) Remove the 3 screws and the power window master switch.
Installation
WINDSHIELD / WINDOWGLASS: POWER WINDOW MASTER SWITCH: INSTALLATION
INSTALLATION
1. INSTALL POWER WINDOW MASTER SWITCH
(a) Install the power window master switch with the 3 screws.
2. INSTALL FRONT ARMREST BASE UPPER PANEL LH
HINT: Use the same procedure as for the RH side See: Body and Frame/Doors, Hood and Trunk/Doors/Front Door/Service and
Repair/Reassembly.
