xD L4-1.8L (2ZR-FE) (2008)
(d) Install the magnet switch body with the 2 screws.
Torque: 7.5 Nm (76 kgf-cm, 66 in-lbf)
(e) Connect the lead wire to the terminal C with the nut.
Torque: 10 Nm (102 kgf-cm, 7 ft-lbf)
(d) Install the magnet switch body with the 2 screws.
Torque: 7.5 Nm (76 kgf-cm, 66 in-lbf)
(e) Connect the lead wire to the terminal C with the nut.
Torque: 10 Nm (102 kgf-cm, 7 ft-lbf)
