Leon Mk1
Removing and applying the stickers on the front wings |
t | Hot air blower -SAT 1416- |
t | Digital thermometer -SAT 4013- |
t | Thrust piece -T20098- |
t | Lever -U 30800- |
t | Adhesive strip remover -VAS 6349- |
|
Installing |
– | Clean the area of the front wing where the new sticker is to be attached with isopropanol or heptanol. |
– | Then clean the area on the tailgate where the sticker is to be attached with silicone cleaner. |
– | Allow to dry well. |
– | Using the hot air blower -SAT 1416-, heat the application area on the bodywork to approx. 35°C. Check the temperature using the digital thermometer -SAT 4013-. |
– | Remove the backing foil -2- from the gluing strip for the new sticker. |
– | Position sticker at distance of 12 mm as shown in figure. |
– | Attach sticker -3- and press down with pressure tool -T20098- with force of approx 5 kg. |
– | Remove backing foil -1- from stickers. |
