Power Door Lock Switch: Testing and Inspection

Rear Gate Release Switch

INSPECTION

1. Disconnect the harness connector of the rear gate release switch.

2. Inspect the continuity between the rear gate release switch connector terminals.

If NG, replace the rear gate release switch.
