Forester F4-2.5L SOHC (2004)
Front Door Latch: Service and Repair
REMOVAL
1. Disconnect the ground cable from battery.
2. Remove the front door trim.
3. Remove the sealing cover.
4. Remove the front inner remote.
5. Remove two bolts and nut, and then remove the guide rail.
6. Remove the three screws and bolt.
7. Remove the front door latch assembly, and then disconnect the connector.
INSTALLATION
Install in the reverse order of removal.
NOTE: Make sure the lock works properly after installation.
