Forester F4-2.5L SOHC (2004)
Front Door Window Glass: Adjustments
ADJUSTMENT
NOTE: Before adjustment, ensure that all adjusting bolts of stabilizer, upper stopper, and sash are loose and door glass is raised so that it is in contact
with weatherstrip.
1. Temporarily tighten one adjusting bolt on one side of rear sash at the midpoint of slotted hole in the inner panel.
2. Temporarily tighten the regulator B-channel in a position at the top of slotted hole.
3. Lower the door glass 10 to 15 mm (0.39 to 0.59 in) from fully closed position. While applying outward pressure of 45.0 ± 5 N (4.6 ± 0.5 kg, 11.0
± 1.1 lb) (F) to upper edge of glass above midpoint of two outer stabilizers, press the inner stabilizer at pressure of 25 ± 5 N (2.5 ± 0.5 kg, 5.5 ±
1.1 lb) to the glass, then secure it.
4. For adjustment of clearance between front glass and center pillar cover, loosen the nuts A., and move the rear sash back and forward until
clearance becomes the value shown. (Clearance between upper side and lower side is within 15 mm (0.059 in).)
