NOTE:  Remove the clip at "C" area upwards while applying sideway force to deflect hook at "a" area.

INSTALLATION

Install in the reverse order of removal.

CAUTION:  Be careful not to scratch the body panels with roof rail stud bolts when removing and installing them.

Tightening torque: 7.5 N.m (0.76 kgf-m, 5.53 ft-lb)
