Forester F4-2.5L SOHC (2004)
^
Cable end portion of lever
Grease: SUNLIGHT 2 (Part No. 003602010)
3) Adjust the PHV cable.
CAUTION: After replacing the PHV cable with new one, operate the clutch pedal about 30 times as a running-in operation prior to
adjustment.
D: ADJUSTMENT
Confirm stopping and starting performances by activating the hill holder on an uphill road of 3° or higher inclination.
1) If the vehicle does not stop;
Tighten the adjusting nut of PHV cable.
2) If the vehicle does not start properly;
^
Case A-When the hill holder is released later than engagement of clutch pedal (Engine tends to stall.):
Loosen adjusting nut gradually until smooth starting is enabled.
^
Case B-When the hill holder is released earlier than engagement of clutch pedal (Vehicle slips down slightly.):
Tighten the adjusting nut so that hill holder is released later than engagement of clutch pedal (status in Case A). Then make adjustment the
same as in Case A.
CAUTION: Whenever turning the adjusting nut, prevent the PHV cable from revolving.
3) Tighten the lock nut.
Tightening torque: 3.4 Nm (0.35 kgf-m, 2.5 ft. lbs.)
