Forester F4-2.5L SOHC (2004)
16. Remove the baffle plate.
INSTALLATION
CAUTION: Before installing the oil pan, clean sealant from oil pan and engine block.
1. Check the seal (A) is securely installed in baffle plate in the direction as shown in the figure.
2. Install the baffle plate.
Tightening torque: 6.4 Nm (0.65 kgf-m, 4.7 ft. lbs.)
3. Install the oil strainer onto baffle plate.
NOTE: Replace the O-ring with a new one.
Tightening torque: 10 Nm (1.0 kgf-m, 7.2 ft. lbs.)
