Cigarette Lighter: Service and Repair

REMOVAL

1. Disconnect the ground cable from battery.
2. Remove the front cover. <Ref. to REMOVAL, Console Box.>

3. Disconnect the harness connectors and remove cigarette lighter.

INSTALLATION

Install in the reverse order of removal.
