Forester F4-2.5L SOHC (2004)
Oil Filter: Service and Repair
Engine Oil Filter
REMOVAL
1. Remove six clips on the under cover.
2. Turn the service hole cover counterclockwise.
3. Remove the oil filter with ST.
ST 498547000 OIL FILTER WRENCH
INSTALLATION
1. Get a new oil filter and apply a thin coat of engine oil to the seal rubber.
2. Install the oil filter by turning it by hand, being careful not to damage seal rubber.
3. Tighten more (approx. 2/3 to 3/4 turn) after the seal rubber contacts the oil pump case. Do not tighten excessively, or oil may leak.
INSPECTION
1. After installing the oil filter, run the engine and make sure that no oil is leaking around seal rubber.
NOTE: The filter element and filter case are permanently jointed; therefore, interior cleaning is not necessary.
2. Check the engine oil level.
