Forester F4-2.5L SOHC (2004)
Accelerator Pedal: Service and Repair
Removal and Installation
REMOVAL
1. Disconnect the ground cable from battery.
2. Remove the lock nut from accelerator cable bracket.
3. Separate the accelerator cable from bracket.
4. Remove the accelerator cable end from throttle cam.
NOTE: Be careful not to kink the accelerator cable.
5. Remove the clip inside engine compartment.
6. Remove the instrument panel lower cover from instrument panel.
7. Remove the accelerator pedal connecting bolt from accelerator pedal bracket.
