6. Remove the service hole cover.
7. Disconnect the connector from the fuel sub meter.

8. Disconnect the fuel jet pump hose.

9. Remove the bolts which install the fuel sub meter unit on the fuel tank.

10. Remove the fuel sub meter unit.

INSTALLATION
