Forester F4-2.5L SOHC (2004)
Ambient Temperature Sensor / Switch HVAC: Testing and Inspection
AMBIENT SENSOR
TROUBLE SYMPTOM:
-
Fan speed is not switched when the fan speed control dial is in AUTO position.
-
Malfunction related to ambient sensor is indicated in self-diagnosis.
Wiring Diagram
WIRING DIAGRAM:
