Steering Shaft: Testing and Inspection

INSPECTION

If the vehicle is involved in a collision on any side, even if it is a slight collision, be sure to check the following system parts.

STEERING SHAFT

Check for the following, and replace damaged parts with new parts. Overall length of steering column should be within specifications.

Specifications:  Overall length L .......................815.6±1.5 mm (32.1±0.06 in)

If necessary, replace it with a new part.
