Forester F4-2.5L SOHC (2004)
NOTE: When disconnecting the outlet pipe, be careful not to lose ball and spring used with retaining screw.
INSTALLATION
1. Install the oil cooler outlet and inlet pipes with new washer.
Tightening torque:
T1: 25 Nm (2.5 kgf-m, 18.1 ft. lbs.)
T2: 44 Nm (4.5 kgf-m, 32.5 ft. lbs.)
2. Install the ATF cooler pipe to frame.
3. Connect the ATF cooler hose to pipe transmission side.
