Forester F4-2.5L SOHC (2004)
3. After bleeding air from the operating cylinder, ensure that clutch operates properly.
2. Install in the reverse order of removal. Before installing the operating cylinder, apply grease (SUNLIGHT 2: P/N 003602010 to contact point of
the release lever and operating cylinder.
Tightening torque:
T7: 18 Nm (1.8 kgf-m, 13.0 ft. lbs.)
T2: 37 Nm (3.8 kgf-m, 27.5 ft. lbs.)
3. After bleeding air from the operating cylinder, ensure that clutch operates properly.
INSPECTION
1. Check the operating cylinder for damage. If operating cylinder is damaged, replace it.
2. Check the operating cylinder for fluid leakage or damage on boot. If any leakage or damage is found, replace the operating cylinder.
