9. Install V-belts.

10. Install radiator main fan assembly and sub fan motor assembly.

11. Install reservoir tank.

12. Connect over flow hose.
13. Lift-up the vehicle.

14. Connect radiator outlet hose (A) and heater hose (B) (AT vehicles) to water pump.
