Impreza 2.5 RS Coupe AWD F4-2.5L SOHC (2001)
CAUTION:
^
Be careful not to bend clutch cable too much.
^
Never fail to cover outer cable end with boot.
^
Be careful not to kink accelerator cable.
^
Make sure that holder and casing cap are securely connected.
2. Adjust clutch pedal (2500 cc model)
3. Inspect after pedal installation
C: DISASSEMBLY
1. Remove the clip, and then remove the accelerator pedal from the bracket.
2. Pull out the spring pin, and then remove the accelerator pedal from the accelerator pedal lever.
D: ASSEMBLY
Assemble in the reverse order of disassembly.
CAUTION: Clean and apply grease to spacer and inside bore of a accelerator pedal.
