Impreza 2.5 RS Coupe AWD F4-2.5L SOHC (2001)

Page 1
background image

Fuel Tank Cut Valve: Service and Repair

Fuel Cut Valve

REMOVAL

1. Remove fuel tank.

2. Remove protect cover.
3. Disconnect evaporation hose from fuel cut valve.

4. Remove fuel cut valve.

INSTALLATION
