Impreza 2.5 RS Coupe AWD F4-2.5L SOHC (2001)
race.
10. Install circlip in the groove on DOJ outer race.
NOTE:
^
Assure that the balls, cage and inner race are completely fitted in the outer race of DOJ.
^
Exercise care not to place the matched position of circlip in the ball groove of outer race.
^
Pull the shaft lightly and assure that the circlip is completely fitted in the groove.
11. Apply an even coat of the specified grease [20 to 30 g (0.71 to 1.06 oz.)] to the entire inner surface of boot. Also apply grease to shaft.
12. Install DOJ boot taking care not to twist it.
NOTE:
^
The inside of the larger end of DOJ boot and the boot groove shall be cleaned so as to be free from grease and other substances.
^
When installing DOJ boot, position outer race of DOJ at center of its travel.
13. Put a band through the clip and wind twice in alignment with band groove of boot.
CAUTION: Use a new band.
14. Pinch the end of band with pliers. Hold the clip and tighten securely.
NOTE: When tightening boot, exercise care so that the air within the boot is appropriate.
15. Tighten band by using ST.
ST 925091000 BAND TIGHTENING TOOL
NOTE: Tighten band until it cannot be moved by hand.
16. Tap on the clip with the punch provided at the end of ST.
ST 925091000 BAND TIGHTENING TOOL
CAUTION: Tap to an extent that the boot underneath is not damaged.
