Impreza 2.5 RS Coupe AWD F4-2.5L SOHC (2001)
2. Increase the upward travel of window glass up to the position where upper edge just touches weatherstrip surface with door closed.
3. After adjustment, temporarily tighten stoppers.
NOTE: Make sure that each glass stopper is touched.
5. REMEDY FOR INCORRECT CONTACT OF DOOR GLASS TO WEATHERSTRIP
1. Close front door and raise door glass.
2. If clearance is below specifications, loosen bolt A) and bolt B).
3. If clearance is over specifications, tighten bolt A) and bolt B).
6. FIT ADJUSTMENT
Door glass fit is adjusted by displacing the glass front edge with a stabilizer.
NOTE: Before adjusting glass fit, visually check to determine relative adjusting positions of retainer and molding on roof side) and glass surface.
1. Alternately adjust two rear sash adjusting bolts A) until dimensions are obtained.
CAUTION: Do not loosen two adjusting nuts A) at the same time, as this moves sash fore and aft, creating unequal glass- to-sash clearance.
During adjustment, loosen only one nut and keep the other tightened.
