Impreza WRX F4-2.0L DOHC Turbo (2004)
Mud Flap: Service and Repair
MUD GUARD
REMOVAL
1. Jack-up the vehicle.
2. Remove the screws and clips to remove mud guard.
INSTALLATION
Insert the hook into body, and tighten it with screw and clip.
Tightening torque:
T: 14 N.m (1.42 kgf-m, 10.3 ft-lb)
