Body Control Module: Service and Repair

Body Integrated Module

REMOVAL

1) Disconnect the ground cable from battery.
2) Remove the lower cover.

3) Remove the knee bolster.

4) Disconnect the connector from body integrated module.
5) Remove the body integrated module.

INSTALLATION

Install in the reverse order of removal.
