Impreza WRX F4-2.5L DOHC Turbo (2006)
Check Valve: Customer Interest
Wipers/Washers - Poor Front/Rear Washer Nozzle Operation
NUMBER: 07-55-06
DATE: 04/04/06
APPLICABILITY:
2006MY Forester and Impreza
SUBJECT:
Poor Windshield Washer Fluid Spray
Introduction
If you encounter a customer complaint that the windshield washer fluid does not spray properly from the front or rear washer nozzle, there is the
possibility that the nozzle or check valve is clogged or the fluid hose could be pinched or bent. Use the following repair procedure to check and repair as
necessary.
Production Line Change
The check valve was changed from a ball type to a rubber type to prevent clogging. The new style check valve was used in production starting in
October, 2005 with the VINs shown.
Parts Information
Repair Procedure/Information
1)
Check the washer nozzle for contamination. If the spray hole is clogged with wax, dust or foreign material, blow compressed air to the spray hole
of the washer nozzle to clear the obstruction.
2)
Check the washer nozzle fluid hose. Make sure the hose is not pinched, and that it does not have severe bends or kinks.
3)
Check the rear washer hose running along the left sill, as well as the hose in the tailgate area, to ensure that the hose is not pinched or bent,
restricting the flow.
4)
If there is no problem found in step 1 or 2, install a modified check valve.
Front check valve on Forester and Impreza
