Legacy F4-2.5L DOHC Turbo (2005)
Wiper Arm: Service and Repair
Rear
Rear Wiper Arm
REMOVAL
1. Detach the wiper arm cover (A).
2. Remove the nut (B) to remove wiper arm.
INSTALLATION
1. Install in the reverse order of removal.
2. Operate the rear wiper once.
3. Align the blade with the marking (A) of glass.
Tightening torque:
T1: 7.5 N.m (0.77 kgf-m, 6.0 ft-lb)
T2: 8.0 N.m (0.82 kgf-m, 5.9 ft-lb)
