(c) Tighten nuts which install front catalytic converter to center exhaust pipe.

Tightening torque: 35 ± 5 Nm (3.6 ± 0.5 kg-m, 26.0 ± 3.6 ft. lbs.)

(d) Tighten bolt which installs front exhaust pipe on bracket.

Tightening torque: 24 ± 3 Nm (2.4 ± 0.3 kg-m, 17.4 ± 2.2 ft. lbs.)

10. Connect connector to rear oxygen sensor. (Except California 2200 cc model)

11. Lower the vehicle.

CAUTION:  At this time, lower lifting device and release steel cables.

12. Remove lifting device and steel cables.
