Legacy Sedan 2WD F4-2.2L SOHC (1990)
Crankshaft Position Sensor: Testing and Inspection
Crank Angle Sensor Schematic
A faulty crank angle sensor will set code 11 in the on-board diagnostic system. Refer to the schematic diagram and test the sensor with the diagnostic
chart.
CRANK ANGLE SENSOR DIAGNOSTIC CHART
Crank Angle Sensor Diagnostic Chart
CHECK CRANK ANGLE SENSOR
Crank Angle Sensor Testing
1. Disconnect crank angle sensor connector.
2. While cranking engine, check that voltage between connector terminals varies synchronously with engine revolutions (0.1 V min.).
CHECK HARNESS BETWEEN ECU AND CRANK ANGLE SENSOR
1. Disconnect ECU and crank angle sensor connectors.
