Outback F6-3.0L DOHC (2006)
INSTALLATION
1. OUTER SEAT BELT ASSEMBLY
Install in the reverse order of removal.
CAUTION:
-
The parts of driver and passenger sides are not identical. Before installation, make sure that the correct part is used.
-
Be careful not to twist the seat belts during installation.
2. INNER SEAT BELT ASSEMBLY
Install in the reverse order of removal.
CAUTION:
-
Be sure to perform the system calibration for passenger detection system after passenger's seat installation.
Failure to do so may cause improper activation of passenger's airbag.
-
After driver's and passenger's inner seat belts installation, check that the seat belt buckle switch operates normally using Subaru Select Monitor
on the {Status Data} of Airbag System.
Improper buckle switch function may cause airbag system malfunction. Inner seat belt assembly harness (1) must be routed securely as shown
in the figure, since it may affect the performances of seat position sensor and occupant detection system.
-
Driver's Seat
