Tribeca F6-3.6L (2008)

Page 2
background image

INSTALLATION

Install in the reverse order of removal.

INSPECTION

1) Replace the V-belt, if cracks, fraying or wear is found.
2) Make sure that the V-belt automatic belt tension indicator (A) is within the range (D).
