14. Remove the front timing belt cover.
15. Using the crankshaft gear bolt, rotate the crankshaft clockwise until the timing mark on the crankshaft gear is aligned with the notch at the bottom
of the rear timing belt cover.
16. Align the camshaft gears with the notch on the camshaft cover.
17. Remove the timing belt.
18. Loosen the automatic tensioner bolt. Turn the hex-key tab to relieve belt tension.
