Timing Belt: Specifications (page 11 of 12)
- Make
- Suzuki
- Model
- Forenza
- Engine
- L4-2.0L
- Year
- 2004
- Section
- Timing Belt
7. Recheck the automatic tensioner pointer.
8. Install the front timing belt cover.
9. Install the front timing belt cover bolts.
Tighten: Tighten the front timing belt cover bolts to 6 Nm (53 inch lbs.).
10. Install the right engine mount bracket.
11. Install the crankshaft pulley.
12. Install the crankshaft pulley bolts.
Tighten: Tighten the crankshaft pulley bolts to 20 Nm (15 ft. lbs.).
13. Install the serpentine accessory drive belt.
14. Install the right front wheel well splash shield.
15. Install the right front wheel.
16. Install the air cleaner housing.
17. Install the air cleaner housing bolts.
Tighten: Tighten the air cleaner housing bolts to 10 Nm (89 inch lbs.).
18. Connect the air cleaner outlet hose to the throttle body.
19. Connect the breather tube to the camshaft cover.
20. Connect the MAT sensor connector.
