Forenza L4-20L (2004) Starter Motor Service and Repair Instructions
Starter Motor: Overhaul
Starter Motor Disassembly and Assembly
Disassembly
1. Remove the starter. Refer to Starter Removal and Installation.
2. Remove the starter through-bolts.
3. Remove the commutator end frame and brush holder assembly.
4. Inspect the brushes, the pop-out springs, and the brush holders for wear and damage. Replace the assembly, if needed.
5. Check the armature to see if it turns freely. If the armature does not turn freely, break down the assembly immediately, starting with Step 14.
Otherwise, give the armature a no-load test.
