Grand Vitara 2WD V6-2.7L (2006)
Antenna: Service and Repair
Antenna Base Removal and Installation
Removal
1. Remove antenna (1) from antenna base (2).
1. Remove head lining.
1. Disconnect antenna feeder (3) from antenna base (2).
1. Remove antenna base (2) from vehicle.
Installation
Reverse removal procedure noting the following.
-
Tighten antenna base mounting nut to specified torque.
Tightening torque
Antenna base mounting nut a: 10 Nm (1.0 kg-m, 7.5 lb-ft)
