5. Repeat this operation until there are no more air bubbles in hydraulic line.
6. When bubbles stop, depress and hold brake pedal and tighten bleeder plug.

Tightening torque
Front brake caliper bleeder plug: 7 Nm (0.7 kg-m, 5.0 ft. lbs.)
Rear wheel cylinder bleeder plug: 7 Nm (0.7 kg-m, 5.0 ft. lbs.)

7. Then attach bleeder plug cap.
8. After completing bleeding operation, apply fluid pressure to pipe line and check for leakage.
9. Replenish fluid into reservoir up to "MAX" level.
