Grand Vitara JS 2WD V6-2.5L (1999)

  • Engine, Cooling and Exhaust
  • Engine
  • Compression Check
  • System Information
  • Specifications

Page 1
background image

Compression Check: Specifications



Compression Pressure (Cranking Speed of at Least 200 rpm)

Standard

14 - 16 kg/cm2









Limit

13.0 kg/cm2











Maximum Between Cylinders

1.0 kg/cm2
