Kizashi AWD L4-2.4L (2010)
8. Apply adhesive (1) as shown in figure.
CAUTION:
-
Attach windshield (2) on body within 5 minutes from applying adhesive.
-
Use rubber sucker grip to carry glass after adhesive is applied.
Adhesive amount and application area on windshield
Width of adhesive "a": Approx. 7.0 mm (0.28 in.)
Height of adhesive "b": Approx. 15.0 mm (0.59 in.)
Application area "c": Approx. 4.3 mm (0.17 in.), "d": Approx. 4.9 mm (0.19 in.),
"e": Approx. 10.7 mm (0.42 in.)
