Windshield: Service and Repair

Windshield Removal And Installation

Tools Required:

J-24402 Glass Sealant Remover

Removal

1. Remove the cowl vent grille.
2. Remove the inside rearview mirror.
3. Remove the weatherstrip around the windshield.

4. Using the glass sealant remover J-24402, cut the adhesive around the windshield.

5. Remove the windshield from the vehicle.
