Sidekick L4-1324cc 1.3L SOHC 5 Carb 8V (1989)
INSPECTION OF WARNING CONTROLLER/BUZZER
INCORRECT
First connect positive (+) terminal of battery to terminals (2) and (5) of controller and negative (-) one to (7) and then disconnect connection to terminal
(5). If buzzer emits buzzing sound, then controller is in good condition. If not, replace.
CORRECT
First connect positive (+) terminal of battery to TERMINAL (2) of controller and negative (-) one to TERMINALS (6) AND (7) OF CONTROLLER. If
buzzer emits buzzing sound, then controller is in good condition. If not, replace.
