Torque Converter Clutch Relay: Locations
Lock-Up Relay (Automatic Transmission)

Fuel Injection Component Locations

On RH Fender Apron

Relays and Modules
Relays and Modules - Transmission and Drivetrain / Relays and Modules - A/T / Torque Converter Clutch Relay / Lock-Up Relay (Automatic Transaxle)
