Sidekick Sport 2D JX 4WD L4-1.8L (1998)
Backup Lamp Switch: Service and Repair
BACK UP LIGHT SWITCH
WARNING: Refrain from work while exhaust center pipe is hot.
REMOVAL AND INSTALLATION
NOTE: When replacing switch, use care not to let dust enter transmission through switch hole.
1. Lift up vehicle.
2. Remove coupler(s) for switch wiring.
3. Replace switch, connect and clamp as they were.
4. When back up light switch has been replaced, check switch for proper function with ignition switch turned ON and gear shifted to reverse position.
Turn OFF switch after checking its function.
INSPECTION OF 4WD SWITCH AND BACK UP LIGHT SWITCH
1. Undo clamp at the back of intake manifold and then disconnect coupler.
