Sidekick Sport 2D JX 4WD L4-1.8L (1998)
Clutch Switch: Adjustments
Cable Type
CLUTCH PEDAL POSITION SWITCH (CPP SWITCH)
ADJUSTMENT
1. Apply parking brake firmly and place gear shift control lever in neutral position.
2. Disconnect lead wire coupler beside the pedal bracket.
3. Loosen lock nut and screw the switch out.
4. Depress clutch pedal all the way to the floor, and then return it back 20 - 30 mm (0.8 -1.2 inch) along its travel from the floor.
Travel "a": 20 - 30 mm (0.8 - 1.2 inch)
5. Connect ohmmeter to the switch, and slowly screw in until it is ON. Hold the switch at this position, and tighten lock nut to specification.
6. Connect lead wire.
CAUTION: When clutch pedal is fully depressed, clearance "b" (remaining switch stroke) should be more than 2 mm (0.08 inch) with this
adjustment. Travel "a " more than specification may cause "b" to be less than 0.5 mm (0.02 inch) and consequential damage of switch bracket.
Tightening Torque
(a): 13 Nm (1.3 kg-m, 9.5 ft. lbs.)
