Swift L4-1298cc 1.3L SOHC MFI (1997)

Page 1
background image

Malfunction Indicator Lamp: Testing and Inspection

1. Turn ON ignition switch (but the engine at stop) and check that MIL lights.

If MIL does not light up, go to "Diagnostic Flow Chart A-1 " for troubleshooting.

2. Start engine and check that MIL turns OFF.

If MIL remains ON and no DTC is stored in ECM, go to "Diagnostic Flow Chart A-2" for troubleshooting.
