XL-7 Plus 4WD V6-2.7L (2002)
Door Lock Cylinder: Testing and Inspection
Door Lock Key Circuit
1. Disconnect negative (-) cable at battery.
2. Disconnect coupler of power door lock and keyless entry controller.
3. Check for continuity between the following terminals at each condition. If check result is satisfactory, this circuit is OK.
Door lock key and power door lock switch circuit (for keyless entry controller) specification
